NANTONG ALLMAN INDUSTRY CO., LTD is a leading player in the machinery industry, specializing in electric chain hoists, wire rope hoists, electric winches, manual chain hoists, and beam trolleys.
| Model | Capacity (t) |
Control Voltage |
Power Supply |
No. of Chain Fall |
Insulation Class |
Lifting Motor (Inverter) |
Travelling Motor (Inverter) |
||||
| Lifting Speed (m/min) |
Motor Power (kw) |
Rotation Speed (r/min) |
Travelling Speed (m/min) |
Motor Power (kw) |
Rotation Speed (r/min) |
||||||
| 0.5-01ER | 0.5 | 24V/36V/48V | 3P 220V-525V 50/60Hz |
1 | F | 2.1-8.2 | 0.8 | 1440 | 3-11 or 19 | 0.4 | 1440 |
| 01-01ER | 1 | 1 | 1.8-7.2 | 1.5 | 0.4 | ||||||
| 01-02ER | 1 | 2 | 1.1-4.1 | 1.5 | 0.4 | ||||||
| 02-01ER | 2 | 1 | 1.8-7.2 | 3.3 | 0.4 | ||||||
| 02-02ER | 2 | 2 | 0.9-3.6 | 1.5 | 0.4 | ||||||
| 03-01ER | 3 | 1 | 1.8-5.6 | 3.3 | 0.4 | ||||||
| 03-02ER | 3 | 2 | 1.1-4.5 | 3.3 | 0.4 | ||||||
| 05-02ER | 5 | 2 | 0.8-3.3 | 3.3 | 0.4 | ||||||
Our 5 ton ER Series Low Headroom Type Electric Chain Hoist is the perfect solution for lifting heavy loads with ease. With a low headroom design, this electric chain hoist is ideal for spaces with limited clearance, making it the perfect choice for manufacturing and maintenance applications. Equipped with a powerful motor and high-quality chain, this hoist can effortlessly lift up to 5 tonnes of weight. It is also equipped with advanced safety features to ensure maximum protection for users and the load being lifted. Our ER Series hoist is easy to operate and offers reliable performance, making it an excellent investment for any business looking to increase productivity and efficiency.
