NANTONG ALLMAN INDUSTRY CO., LTD is a leading player in the machinery industry, specializing in electric chain hoists, wire rope hoists, electric winches, manual chain hoists, and beam trolleys.
| Model | Capacity (t) |
Control Voltage |
Power Supply |
No. of Chain Fall |
Insulation Class |
Lifting Motor (Inverter) |
Travelling Motor (Inverter) |
||||
| Lifting Speed (m/min) |
Motor Power (kw) |
Rotation Speed (r/min) |
Travelling Speed (m/min) |
Motor Power (kw) |
Rotation Speed (r/min) |
||||||
| 0.5-01ER | 0.5 | 24V/36V/48V | 3P 220V-525V 50/60Hz |
1 | F | 2.1-8.2 | 0.8 | 1440 | 2.1-8.2 | 0.8 | 1440 |
| 01-01ER | 1 | 1 | 1.8-7.2 | 1.5 | 1.8-7.2 | 1.5 | |||||
| 01-02ER | 1 | 2 | 1.1-4.1 | 1.5 | 1.1-4.1 | 1.5 | |||||
| 02-01ER | 2 | 1 | 1.8-7.2 | 3.3 | 1.8-7.2 | 3.3 | |||||
| 02-02ER | 2 | 2 | 0.9-3.6 | 1.5 | 0.9-3.6 | 1.5 | |||||
| 03-01ER | 3 | 1 | 1.8-5.6 | 3.3 | 1.8-5.6 | 3.3 | |||||
| 03-02ER | 3 | 2 | 1.1-4.5 | 3.3 | 1.1-4.5 | 3.3 | |||||
| 05-02ER | 5 | 2 | 0.8-3.3 | 3.3 | 0.8-3.3 | 3.3 | |||||
The 5 ton ER Series Electric Chain Hoist with Electric Trolley is designed for heavy-duty material handling in the machinery industry. This hoist offers a range of features like an electric trolley that allows for easy movement of materials, durable construction, and a powerful motor for efficient lifting. With its advanced features such as overload protection, adjustable speed settings, and a user-friendly interface, this hoist is perfect for various applications. Additionally, its compact design and lightweight construction make it easy to handle and install. Invest in the 5 ton ER Series Electric Chain Hoist for safe and efficient material handling.
