NANTONG ALLMAN INDUSTRY CO., LTD is a leading player in the machinery industry, specializing in electric chain hoists, wire rope hoists, electric winches, manual chain hoists, and beam trolleys.
| Model | Capacity (t) |
Control Voltage |
Power Supply |
No. of Chain Fall |
Insulation Class |
Lifting Speed (m/min) |
Lifting Motor Power (kw) |
Travelling Speed (m/min) |
Travelling Motor Power (kw) |
Rotation Speed (r/min) |
| 0.5-01L | 0.5 | 24V/36V/48V | 3P 220V-690V | 1 | F | 7.2 | 0.8 | 21 | 0.4 | 1440 |
| 01-01L | 1 | 1 | 6.6 | 1.5 | 21 | 0.4 | ||||
| 02-01L | 2 | 1 | 6.6 | 3 | 21 | 0.4 | ||||
| 02-02L | 2 | 2 | 3.3 | 1.5 | 21 | 0.4 | ||||
| 03-01L | 3 | 1 | 5.4 | 3 | 21 | 0.75 | ||||
| 03-02L | 3 | 2 | 4.4 | 3 | 21 | 0.75 | ||||
| 05-02L | 5 | 2 | 2.7 | 3 | 11 | 0.75 |
The 5 ton AMEH Series Low Headroom Type Electric Chain Hoist is the perfect solution for lifting heavy loads with ease. It comes equipped with a low headroom design that makes it ideal for tight spaces and a 5-ton capacity that can handle your toughest jobs. With powerful electric motors and precision-engineered components, this chain hoist is built to last and can be used in a variety of applications. Its user-friendly controls make it easy to operate and its lightweight design makes it easy to transport. Plus, with its advanced safety features, you can be sure that your workers and equipment are always protected. Invest in the 5 ton AMEH Series Low Headroom Type Electric Chain Hoist and take your lifting operations to the next level.
